ICPDAS ET-7228
Levertijd:
2~7 dagen
SKU
ET-7228
Ethernet I/O Module with 2-port Ethernet Switch, with 8-channels Analog Output
● Built-in Web Server
● Web HMI
● Support for both Modbus TCP and Modbus UDP Protocols
● Communication Security
● Dual Watchdog
● Wide Operating Temperature Range: -25 ~ +75°C
● I/O Pair Connection
● 8 channel Analog Output
The ET-7228 is a multifunction module with 8 channels analog output. It provides a variety of programmable analog output options (+/-5 V, +/-10 V, 0 ~ 20 mA and 4 ~ 20 mA), and each analog output can be programmed to accept either current or voltage as output depending upon the position of corresponding jumper.
Meer informatie
Art.nr.
ET-7228
Fabrikant
ICPDAS
Software
| Built-In Web Server | Yes |
| Web HMI | Yes |
| I/O Pair Connection | Yes |
Communication
| Ethernet Port | 2 x RJ-45, 10/100 Base-TX, Swtich Ports |
| Protocol | Modbus/TCP, Modbus/UDP |
| Security | ID, Password and IP Filter |
| Dual Watchdog | Yes, Module (0.8 seconds), Communication (Programmable) |
Analog Output
| Channels | 8 |
| Type | +0 VDC ~ +5 VDC, +/-5 VDC, +0 VDC ~ +10 VDC, +/-10 VDC,+0 mA ~ +20 mA, +4 mA ~ +20 mA (Jumper Selectable) |
| Individual Channel Configuration | Yes |
| Resolution | 12-bit |
| Accuracy | +/-0.1% of FSR |
| Voltage Output Capability | 10V @ 10 mA |
| Current Load Resistance | 500 Ω |
| Open Wire Detection | Yes, for 4 ~ 20 mA only |
| Power-on Value | Yes, Programmable |
| Safe Value | Yes, Programmable |
2-Way Isolation
| Ethernet | 1500 VDC |
| I/O | 2500 VDC |
EMS Protection
| ESD (IEC 61000-4-2) | 4 kV Contact for each terminal and 8 kV Air for random point |
| EFT (IEC 61000-4-4) | ±4 kV for Power |
LED Indicators
| LED | System Running |
| LED | Ethernet Link/Act |
| LED | DO status |
Power
| Reverse Polarity Protection | Yes |
| Powered from Terminal Block | Yes, 12 ~ 48 V DC |
| Powered from PoE | - |
| Consumption | 6 W |
Mechanical
| Dimensions (l x w x h) | 120 x 76 x 38mm |
| Installation | DIN-Rail or Wall Mounting |
Omgeving
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -30 °C ~ +80 °C |
| Humidity | 10 ~ 90% RH, non-condensing |
