EtherWAN Ethernet Switch EX46100

Details

EtherWAN's EX46100 Series provides a hardened 8-port switching platform supporting IEEE802.3af+ Power over Ethernet, high performance switching with robust features required for mission-critical and harsh environments where sustained connectivity is crucial.

The EX46100 Series is equipped with 4 10/100BASE-TX PoE ports, in combination with two 100FX Fiber options.

The IEEE802.3af+ PoE ports provide up to 30W/port with a total power budget of 120W, making the switch truly versatile for connecting with PoE Powered Devices (PD) with different bandwidth and power consumption requirements such as outdoor PTZ dome cameras, wireless access points, and way-side communication devices.

Users are able to access management features such as QoS based on 802.1p, DSCP, and IP precedence. With the hardened specifications, the EX46100 Series is designed to operate at -40°C to 75°C in harsh environments, where high ESD, shock, and vibration may be present.

SPECIFICATIES

Meer informatie

Art.nr.

EX46100

Fabrikant

EtherWAN

Land van herkomst

Taiwan

Technology

Standards	IEEE802.3 10BASE-T, IEEE802.3u 100BASE-TX/FX, IEEE802.3x, IEEE802.3af
Forward and Filtering Rate	14,880pps for 10Mbps 148,810pps for 100Mbps
Packet Buffer Memory	1M bits
Processing Type	Store-and-Forward Half-duplex back-pressure and IEEE802.3x full-duplex flow control
Address Table Size	1024 MAC addresses

Interface

Ethernet Port	10/100BASE-TX: 8, 7 or 6 ports 100BASE-FX: 0, 1 or 2 ports
LED Indicators	Per Unit: Power Status (Power 1, Power 2, Power 3) Per Port: 10/100TX, 100FX: Link/Activity (Green) PoE: Link (Amber)
Alarm Contact	One relay output with current 1A @ 24VDC

Power

Input	Redundant power inputs: Terminal Block: 47 - 57VDC DC Jack: 47 - 57VDC
Power Consumption	Device: Max. 10W (without PoE) PoE power budget (depends on power input):120W Max.
PoE Power Output	Port 1 to 4 IEEE802.3af+: up to 30W/port, 47 - 57VDC, 600mA Max.
Overload Current Protection	Present
Reverse Polarity Protection	Present

Mechanical

Casing	Aluminum case IP30
Dimensions (w x h x d)	68mm (W) x 110mm (D) x 135mm (H) (2.68" (W) x 4.33" (D) x 5.31" (H))
Weight	1Kg (2.2lbs.)
Installation	DIN-Rail (Top hat type 35mm), Panel, Rack Mounting

Environmental

Operating Temperature	-40°C to 75°C (-40°F to 167°F) Tested @ -40°C to 85°C (-40°F to 185°F)
Storage Temperature	-40°C to 85°C (-40°F to 185°F)
Web-smart Function Operating Temperature	-20°C to 75°C (-4°F to 167°F)
Humidity	5% to 95% (non-condensing)

Approvals

ISO	Manufactured in an ISO9001 facility
EMI	FCC Part 15, Class A EN61000-6-4 - EN55022 - EN61000-3-2 - EN61000-3-3
EMS	EN61000-6-2 - EN61000-4-2 (ESD Standards) Contact: + / - 4KVAir: + / - 8KV - EN61000-4-3 (Radiated RFI Standards) 10V/m, 80 to 1000MHz; 80% AM 3V/m, 1400 to 2000MHz; 80% AM 1V/m, 2000 to 2700MHz; 80% AM - EN61000-4-4 (Burst Standards) Signal Ports: + / - 4KV D.C. Power Ports: + / - 4KV - EN61000-4-5 (Surge Standards) Signal Ports: + / - 1KV; Line-to-Line D.C. Power Ports: + / - 0.5KV; Line-to-Earth - EN61000-4-6 (Induced RFI Standards) Signal Ports: 10Vrms @ 0.15 - 80MHz; 80% AM D.C. Power Ports: 10Vrms @ 0.15 - 80MHz; 80% AM - EN61000-4-8 (Magnetic Field Standards) 30A/m @ 50, 60Hz
Environmental Test Compliance	IEC60068-2-6 Fc (Vibration Resistance) 5g @ 10 - 150Hz, Amplitude 0.35mm (Operation/Storage/Transport) IEC60068-2-27 Ea (Shock) 25g @ 11ms (Half-Sine Shock Pulse; Operation) 50g @ 11ms (Half-Sine Shock Pulse; Storage/Transport) FED STD 101C Method 5007.1 (Free fall w/ package) -Tested with Cross Weight and Drop High standard table
