ICPDAS CAN-2018D
DeviceNet Slave Module of 8-channel thermocouple input
● DeviceNet general I/O slave devices
● Comply with DeviceNet specification Volume I,
● Release 2.0 & Volume II, Release 2.0, Errata 5
● Group 2 Only Server (non UCMM-capable)
● Support Predefined Master/Slave Connection Set
● Connection supported:
● 1 connection for Explicit Messaging
● 1 connection for Polled I/O
● 1 connection for Bit-Strobe I/O connection
● Support DeviceNet heartbeat and shutdown messages
● Provide EDS file for DeviceNet master interface
DeviceNet is one kind of the network protocols based on the CAN bus and mainly used for the embedded network of the machine control, such as industrial machine control , aircraft engines monitoring, factory automation, medical equipments control, remote data acquisition, environmental monitoring, and packaging machines control, etc.
The CAN-2018D follows DeviceNet specification Volume I/II, Release 2.0. User can access the thermocouple input status and set the configuration via DeviceNet EDS file. CAN-2018D has 8-channel thermocouple input and it can be used to various applications. By the DeviceNet masters of ICP DAS, you can quickly build a DeviceNet network to approach your requirements.
| DeviceNet Specification | Volume I, Release 2.0 & Volume II, Release 2.0, Errata5 |
| DeviceNet subscribe | Group 2 Only Server |
| Connection supported | 1 connection for Explicit Messaging 1 connection for Polled I/O 1 connection for Bit-Strobe I/O |
| Baud Rate Setting by Rotary Switch | 125 kbps, 250 kbps, 500 kbps |
| PDO Mapping | Available |
| Node ID Setting by Rotary Switch | 0 ~ 63 |
| Heartbeat message | Yes |
| Shutdown message | Yes |
| Terminator Resistor | Switch for 120 Ω terminator resistor |
| Connector | 5-pin screwed terminal block (CAN_GND, CAN_L, CAN_SHLD, CAN_H, CAN_V+) |
| Terminator Resistor | Switch of 120 Ω terminator resistor |
| Connector | 5-pin screwed terminal block (CAN_GND, CAN_L, CAN_SHLD, CAN_H, CAN_V+) |
| EDS file | Yes |
| Channels | 8 |
| Inputt Type | +/- 15mV, +/- 50mV, +/- 100mV, +/- 500mV, +/- 1V, +/- 2.5V +/-20mA,(Requires Optional External 125 Ohm Resistor) Thermocouple (J, K, T, E, R, S, B, N, C) |
| Resolution | 16-bit |
| Accuracy | ± 0.1 % FSR |
| Zero Drift | +/- 10 μV/ °C |
| Span Drift | ±25 ppm/°C |
| Power | PWR, red |
| DeviceNet Status |
NET/MOD, green/orange |
| Power Supply | Unregulated +10 ~ +30 VDC |
| Power Consumption | 1.5 W |
| Installation | DIN-Rail |
| Dimensions (w x l x h) | 33 mm x 99 mm x 78 mm |
| ESD Protection | +/- 4 kV Contact for each terminal |
| Operating Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -30 °C ~ +80 °C |
| Humidity | 10 ~ 90% RH, non-condensing |
