I-7540D CAN-Ethernet Gateway ICPDAS
Levertijd:
Uit voorraad leverbaar
SKU
I-7540D-G
Internet communication controller with one CAN bus, one RS-232, one RS-485 and one Ethernet
● 80186-80 Embedded CPU, or compatible
● Ethernet Protocols, TCP, UDP, IP, ICMP, ARP
● 10/100 Base-TX Ethernet Controller
● Reloadable Operating Software
● Message transmitted by using TCP/IP protocol
● Diagnostics
● COM driver support interrupt & 1K QUEUE Input & Output buffer
● Support one RS-232 port, one RS-485 port and one CAN port
● 2500 Vrms photo-isolation protection on CAN side
● Jumper select 120 Ω terminator resistor for CAN channel
Internet communications using TCP/IP is increasing in the industrial sector. Using Ethernet for network in industrial area is appealing because the required cabling is already installed. The CAN-Ethernet Gateway from ICP DAS is a solution that enables CAN networks to be coupled together over the Internet/Ethernet, whereby remote monitoring and control is possible. The CAN-Ethernet Gateway controls networked communication and makes a transparent CAN-based application interface available to the user.
The device supports a transparent, protocol-independent transfer of the CAN messages, thus allowing its implementation into a wide range of possible applications.
Furthermore, the CAN-Ethernet Gateway can be used with various higher layer CAN protocols (e.g. CANopen, DeviceNet or other proprietary protocols). The following figure shows the application architecture for CAN-Ethernet Gateway . Furthermore, I-7540D also can be used as Ethernet to CAN/RS-232/485 Device Server. The Device Server is an appliance that network enables any device with a serial communication port.
By virtue of its independent operating system, protocol independence, small size and flexibility, Device servers are able to meet the demand of virtually any network-enable application. Most devices don't have network ports. I-7540D allows those devices to become connected to the network.
 |
 |
 |
APPLICATIONS:
● Control System
● Building Automation
● Home Automation
● Control System
● Monitor System
● Vehicle Automation
Meer informatie
Art.nr.
I-7540D-G
Fabrikant
ICPDAS
CAN Interface
| Controller | NXP SJA1000T with 16 MHz clock |
| Transceiver | NXP 82C250 |
| Channel Number | 1 |
| Connector | 2-pin screwed terminal block (CAN_L, CAN_H) |
| Baud Rate | 10k, 20k, 50k, 125k, 250k, 500k, 800k, 1M (allow user-defined baud rate) |
| Isolation | 1000V DC for DC-to-DC, 2500 Vrms for photo-couple |
| Terminator Resistor | Jumper for 120Ω terminator resistor |
| Specification | ISO-11898-2, CAN 2.0A and CAN 2.0B |
UART Interface
| COM 1 | RS-232 |
| COM 1 Connector | 5-pin screwed terminal block (TxD, RxD, RTS, CTS, GND ) |
| COM 2 | RS-485 (Self-turner inside) |
| COM 2 Connector | 2-pin screwed terminal block (DATA+, DATA-) |
| Baud Rate | 110, 150, 300, 600, 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200 |
| Data Bit | 7, 8 |
| Stop Bit | 1 |
| Parity | None, Even, Odd |
Ethernet Interface
| Controller | 10/100Base-TX Ethernet Controller (Auto-negotiating, Auto_MDIX) |
| Connector | RJ-45 with LED indicator |
Power
| Power Supply | Unregulated +10 ~ +30 VDC |
| Protection | Power reverse polarity protection, Overvoltage brownout protection |
| Power Consumption | 2.5W |
Mechanical
| Installation | DIN-Rail |
| Dimensions (w x l x h) | 72 x 33 x 122mm |
Omgeving
| Operation Temperature | -25 °C ~ +75 °C |
| Storage Temperature | -40 °C ~ +80 °C |
| Humidity | 5 ~ 95% RH, non-condensing |
